    DETAILED DESCRIPTION

    MCM260X
    Expansion modules are a good solution for logging and management of remote I/Os and for expanding the basic structure in applications that already include PLCs, PCs or operator terminals. The RS485 serial port with Modbus/RTU protocol and the CANopen high-speed bus allow easy integration (including EDS files for CANopen) into devices from Pixsys and other manufacturers.
    The devices are included in the Pixsys catalogue, inside the LogicLab development tool for quick integration into projects to be developed.
    There are 6 part numbers available for solutions providing different combinations of analogue, digital or relay inputs and outputs.
    A special parameter configuration allows to repeat the operation of the previous MCM260, ensuring full compatibility between the two series.
    Addressing and setting of communication parameters are possible by using a 4-digit display and  function keys under the front panel, or by NFC through MyPixsys App, like the latest Pixsys devices.

    Specifications

    • Dimensions: 90 x 71 x 58 (H) mm with DIN RAIL mounting fitting EN50022
    • Power supply: 12-24V AC/DC ± 15% 50/60 Hz
    • Power Consumption: 2-4VA
    • Operating conditions: Temperature 0-500°C, humidity 35..95 uR% (non condensing)
    • Sealing protection: IP30
    • Wiring: Extractable terminal blocks
    • Bus Protocol: Modbus RTU slave (RS485 max. 115200 Baud) or CAN Open (max 1 Mbit/sec) with EDS file for net configuration
    • HMI - Operator interface: TD410/ TD710/ TD810 /TD820/ TD750/ TD850/ TD900-910-920/ third-party SCADA for control or supervision of any industrial plants

    Hardware characteristics and order codes

    • MCM260X-1AD: Power supply 12..24 Vdc, 16xStatic Outputs 12..24Vdc
    • MCM260X-2AD: Power supply 12..24 Vdc, 16xDigital inputs PNP 12..24Vdc, 2xAnalog inputs 0-10V, 3xEncoders/Counters
    • MCM260X-3AD: Power supply 12..24 Vdc, 8xDigital inputs PNP 12..24Vdc, 8xStatic Outputs 12..24Vdc, 3xEncoders/Counters
    • MCM260X-4AD: Power supply 12..24 Vdc/Vac, 8xDigital inputs PNP 12..24Vdc, 8xRelay outputs, 2xAnalog inputs 0-10V, 3xEncoders/Counters MCM260X-5AD: Power supply 12..24 Vdc/Vac, 4xUniversal analog inputs, 2xAnalog outputs 0-10V / 4..20mA
    • MCM260X-9AD: Power supply 12..24 Vdc, 4xUniversal analog inputs, 2xAnalog outputs 0-10V / 4..20mA, 16xStatic outputs 12..24Vdc / Digital inputs PNP 12..24Vdc, 4xEncoders/Counters
