857-550, current converter, μετατροπέας έντασης
Current converter 1A or 5A (AC/DC). 857-550 WAGO
Product Inquiry
Product Inquiry
DETAILED DESCRIPTION
857-550
This current converter measures both 0-1 A and 0-5 A AC/DC currents, converting the input signal to an standard analog signal at the output.
Features:
- Output: 0-10, 2-10, 0-20, 4-20 mA or 0-5, 1-5, 0-10, 2-10 V
- PC configuration interface
- True RMS measurement or arithmetic mean value
- Digital switching output (configurable switching thresholds)
- Switchable filter function
- Calibrated measurement range switching
- 3-way electrical isolation with 2.5 kV test voltage
- Extremely fast response times
- Measurement range overflow indication
Configuration
- Configuration options DIP switch
- WAGO Interface Configuration Software
- WAGO Interface Configuration App
